Introducing the switches | 26
Fan redundancy refers to fans and not fan trays. With 2 fan trays installed, it allows 1 fan fault. With 1 fan tray,
there is no fan redundancy.
Fan tray with faulty fan/fans must be replaced with Aruba X751 FB Tray (JL669B).
Power supplies
This section is only applicable to the 6200M switches. Switches in the 6200F family have internal, fixed power
supplies.
The following power supplies can be installed in the 6200M switches:
n
Aruba X371 12VDC 250W 100-240VAC Power Supply (JL085A): A 250 watt power supply for the
non-PoE switches. This power supply does not provide any PoE power, and is keyed so that it will not
fit into the power supply slots of Aruba PoE switches. The following switches support this power
supply:
o
HPEAruba Networking CX 6200M 24G 4SFP+ switch (R8Q67A)
o
HPEAruba Networking CX 6200M 48G 4SFP+ switch (R8Q69A)
o
HPEAruba Networking CX 6200M 24G 4SFP+ TAA switch (R8V08A)
o
HPE Aruba Networking CX 6200M 48G 4SFP+ TAA switch (R8V10A)
n
Aruba X372 54VDC 680W 100-240VAC Power Supply (JL086A): A 680 watt power supply for
applicable PoE switches. Offers up to 370 watts of PoE power, and is keyed so that it will not fit into
the power supply slots of non-PoE Aruba switches. The following switches support this power supply:
o
HPEAruba Networking CX 6200M 24G Class4 PoE 4SFP+ switch (R8Q68A)
o
HPEAruba Networking CX 6200M 24G class4 PoE 4SFP+ TAA switch (R8V09A)
o
HPEAruba Networking CX 6200M 48G Class4 PoE 4SFP+ Switch (R8Q70A)
o
HPEAruba Networking CX 6200M 48G Class4 PoE 4SFP+ TAA Switch (R8V11A)
o
HPEAruba Networking CX 6200M 36G 12SR5 Class6 PoE 4SFP+ Switch (R8Q71A)
o
HPEAruba Networking CX6200M 36G 12SR5 Class6 PoE 4SFP+ TAA Switch (R8V12A)
n
Aruba X372 54VDC 1050W 110-240VAC Power Supply (JL087A): A 1050 watt power supply for
applicable PoE switches. Offers up to 740 watts of PoE power, and is keyed so that it will not fit into
the power supply slots of non-PoE Aruba switches. The following switches support this power supply:
o
HPEAruba Networking CX 6200M 24G Class4 PoE 4SFP+ Switch (R8Q68A)
o
HPEAruba Networking CX 6200M 24G Class4 PoE 4SFP+ TAA Switch (R8V09A)
o
HPEAruba Networking CX 6200M 48G Class4 PoE 4SFP+ Switch (R8Q70A)
o
HPE Aruba Networking CX 6200M 48G Class4 PoE 4SFP+ TAA Switch (R8V11A)
o
HPEAruba Networking CX6200M 36G 12SR5 Class6 PoE 4SFP+ Switch (R8Q71A)
o
HPEAruba Networking CX 6200M 36G 12SR5 Class6 PoE 4SFP+ TAA Switch (R8V12A)
For initial power supply installation, see the Start Here guide that pertains to your power supply unit.
Power connector
The 6200F/M switches do not have a power switch. They will power on when either one or both power
supplies are connected to an active power source.
