HPE ProLiant ML350 Gen10 User Manual

HPE 800W Flex Slot -48VDC Hot Plug Low Halogen Power Supply
Specification Value
Input requirements
Rated input voltage
-40 VDC to -72 VDC
-48 VDC nominal input
Rated input current
24 A at -40 VDC input
19 A at -48 VDC input, nominal input
12.4 A at -72 VDC input
Rated input power (W)
874 W at -40 VDC input
865 W at -48 VDC input, nominal input
854 W at -72 VDC input
Rated input power (BTUs per hour)
2,983 at -40 VDC input
2,951 at -48 VDC input, nominal input
2,912 at -72 VDC input
Power supply output
Rated steady-state power (W) 800 W at -40 VDC to -72 VDC
Maximum peak power (W) 800 W at -40 VDC to -72 VDC
Maximum peak power
800 W at 200 VAC to 277 VAC input
800 W at 380 VDC input
WARNING:
To reduce the risk of electric shock or energy hazards:
• This equipment must be installed by trained service personnel, as defined by the NEC and IEC
60950-1, Second Edition, the standard for Safety of Information Technology Equipment.
• Connect the equipment to a reliably grounded secondary circuit source. A secondary circuit has no
direct connection to a primary circuit and derives its power from a transformer, converter, or
equivalent isolation device.
• The branch circuit overcurrent protection must be rated 27 A.
178 HPE 800W Flex Slot -48VDC Hot Plug Low Halogen Power Supply

HPE ProLiant ML350 Gen10 Specifications

General

Processor	Intel Xeon Scalable processors
Expansion Slots	Up to 8 PCIe 3.0 slots
Processor Details	Up to 28 cores per processor, supports up to 2 processors
Memory	Up to 3TB DDR4
Storage	Supports SAS, SATA, and NVMe drives
RAID Support	HPE Smart Array
Network	4 x 1GbE ports (embedded)
Power Supply	800W or 1600W Platinum, Hot-Plug, Redundant Power Supply
Form Factor	Tower
Remote Management	HPE iLO 5
Operating System Support	Windows Server, VMware, and various Linux distributions
