hpmont HD20 Series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―126― HD20 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
negative, 0 is the limit)
1: PID regulation enable
reverse (When F00.18 = 1
disable reverse, 0 is the limit)
F04.19
PID output reverse
frequency’s upper limit
0.00Hz－upper limit 50.00Hz 0.01Hz ×
Group F05 External Reference Curve Parameters (refer to pages 62
－
64)
F05.00
External reference curve
selection
Units: AI1 characteristic curve
selection
Tens: AI2 characteristic curve
selection
Hundreds: Reserved
Thousands: Reserved
Ten thousands: Pulse input
characteristic curve selection
0: Line 1
1: Line 2
2: Polyline
00000 1 ×
F05.01
Minimum reference of line
1
0.0%－F05.03 0.0% 0.1% ○
F05.02
Minimum reference
corresponding value of
line 1
0.0－100.0% 0.0% 0.1% ○
F05.03
Maximum reference of line
1
F05.01－100.0% 100.0% 0.1% ○
F05.04
Maximum reference
corresponding value of
line 1
0.0－100.0% 100.0% 0.1% ○
F05.05
Minimum reference of line
2
0.0%－F05.07 0.0% 0.1% ○
F05.06
Minimum reference
corresponding value of
line 2
0.0－100.0% 0.0% 0.1% ○
F05.07
Maximum reference of line
2
F05.05－100.0% 100.0% 0.1% ○
F05.08
Maximum reference
corresponding value of
line 2
0.0－100.0% 100.0% 0.1% ○
F05.09
Maximum reference of
polyline
F05.11－100.0% 100.0% 0.1% ○
F05.10
Maximum reference
corresponding value of
polyline
0.0－100.0% 100.0% 0.1% ○
F05.11
Inflection point 2 reference
of polyline
F05.13－F05.09 100.0% 0.1% ○
F05.12
Inflection point 2
0.0－100.0% 100.0% 0.1% ○
