No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F18.07
Set the display parameter
6 during operation
21: AI1 input voltage (after
disposal)
22: AI2 input voltage
23: AI2 input voltage (after
disposal)
24-27: Reserved
28: DI6 terminal pulse input
frequency
29: AO1 output
30: AO2 output
31: High-speed output pulse
frequency
32: Heatsink temperature
33: Set the line speed
34: Reference line speed
35-36: Reserved
37: Process PID reference
38: Process PID feedback
39: Process PID error
40: Process PID integral value
41: Process PID output
42: External couting value
43: Input terminal status
44: Output terminal status
45: MODBUS communication
status
46: Actual length
47: Total length
48: Total time at power on
(hour)
49: Total time at running (hour)
18 1 ○
F18.08
Set the display parameter
1 at stop
7 1 ○
F18.09
Set the display parameter
2 at stop
18 1 ○
F18.10
Set the display parameter
3 at stop
20 1 ○
F18.11
Set the display parameter
4 at stop
22 1 ○
F18.12
Set the display parameter
5 at stop
43 1 ○
F18.13
Set the display parameter
6 at stop
44 1 ○
F18.14 Reserved
F18.15
Maximum output line
speed
0-65535 1000 1 ○
F18.16
Line speed display
accuracy
0: Integer
1: One decimal
2: Two decimal
3: Three decimal
0 1 ×
Group F19 Function-boost Parameters (refer to pages 94
101)
F19.00
Auxiliary frequency setting
source selection
0: No auxiliary source
1: Digital setting 1 (the initial
value is set by F19.03 and
adjusted by and keys
on the display panel)
2: Digital setting 2 (the initial
value is set by F19.03 and
0 1 ○
