Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －133－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
9999mH
F08.10
Mutual inductance of
motor 1
5.5kW above: 0.0－500.0mH 0.1mH
×
5.5kW or below: 0－5000mH 1mH
F08.11
Idling exciting current
of motor 1
5.5kW above: 0.0－999.9A 0.1A
×
5.5kW or below: 0.00－
99.99A
0.01A
F08.12 Reserved
F08.13 Reserved
F08.14 Reserved
Group F09 V/f Control Parameters (refer to pages 74
－
77)
F09.00
V/f curve selection of
motor 1
0: Line
1: Square curve
2: 1.2 exponential curve
3: 1.7 exponential curve
4: User-defined curve
0 1 ×
F09.01
V/f frequency value F3
of motor 1
F09.03－F08.03 0.00Hz 0.01Hz ×
F09.02
V/f voltage value V3 of
motor 1
F09.04－F08.01 0V 1V ×
F09.03
V/f frequency value F2
of motor 1
F09.05－F09.01 0.00Hz 0.01Hz ×
F09.04
V/f voltage value V2 of
motor 1
F09.06－F09.02 0V 1V ×
F09.05
V/f frequency value F1
of motor 1
0.00－F09.03 0.00Hz 0.01Hz ×
F09.06
V/f voltage value V1 of
motor 1
0－F09.04 0V 1V ×
F09.07
Torque boost of motor
1
0: Auto torque boost
0.1－30.0%
0.1% 0.1% ○
F09.08
Cut-off point used for
manual torque boost of
motor 1
0.0－50.0% (F08.03) 10.0% 0.1% ○
F09.09
Slip compensation gain
of motor 1
0.0－300.0% 100.0% 0.1% ○
F09.10
Slip compensation filter
time of motor 1
0.01－10.00s 0.10s 0.01s ○
F09.11
Slip compensation
limitation of motor 1
0.0－250.0% 200.0% 0.1% ×
F09.12
Compensation
constant of motor 1
0.1－25.0s 2.0s 0.1s ○
F09.13 Reserved
F09.14
AVR function of motor
1
0: Disabled
1: Enabled all the time
2: Disabled in deceleration
1 1 ○
A
