Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―132― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
time
1: The inverter restarts the
wobble operation from 0 Hz
Thousands: Save the wobble
operation parameters at
power outage
0: Saved
1: Not be saved
F07.02
Preset wobble
frequency
0.00－upper limit 0.00Hz 0.01Hz ×
F07.03
Holding time of preset
wobble frequency
0.0－999.9s 0.0s 0.1s ×
F07.04 Wobble amplitude 0.0－50.0% 0.0% 0.1% ×
F07.05 Jump frequency 0.0－F07.04 0.0% 0.1% ×
F07.06 Wobble operation cycle 0.0－999.9s 10.0s 0.1s ×
F07.07
Rising time of triangle
wave
0.0－100.0% (F07.06) 50.0% 0.1% ×
Group F08 Asynchronous Motor 1 Parameters (refer to pages 73
－
74)
F08.00 Rated power of motor 1 0.2－500.0kW
Dependent
on inverter
model
0.1kW ×
F08.01
Rated voltage of motor
1
0－inverter’s rated voltage 1V ×
F08.02
Rated current of motor
1
5.5kW above: 0.0－999.9A 0.1A
×
5.5kW or below: 0.00－
99.99A
0.01A
F08.03
Rated frequency of
motor 1
1.0－400.0Hz 50.0Hz 0.1Hz ×
F08.04 Rated speed of motor 1 1－24000rpm 1440rpm 1rpm ×
F08.05 Power factor of motor 1 0.001－1.000
Dependent
on inverter
model
0.001 ×
F08.06
Parameter auto-tuning
of motor 1
0: Auto-tuning is disabled
1: Stationary auto-tuning
2: Rotary auto-tuning
0 1 ×
F08.07
Stator resistance of
motor 1
5.5kW above: 0.000－
9.999Ω
Dependent
on inverter
model
0.001Ω
×
5.5kW or below: 0.00－
99.99Ω
0.01Ω
F08.08
Rotor resistance of
motor 1
5.5kW above: 0.000－
9.999Ω
0.001Ω
×
5.5kW or below: 0.00－
99.99Ω
0.01Ω
F08.09
Leakage inductance of
motor 1
5.5kW above: 0.0－999.9mH 0.1mH
×
5.5kW or below: 0－
1mH
