Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―136― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F13.15 Reserved
F13.16
V/f curve selection of
motor 2
0: Line
1: Square curve
2: 1.2 exponential curve
3: 1.7 exponential curve
4: User-defined curve
0 1 ×
F13.17
V/f frequency value F3
of motor 2
F13.19－F13.04 0.00Hz 0.01Hz ×
F13.18
V/f voltage value V3 of
motor 2
F13.20－F13.02 0V 1V ×
F13.19
V/f frequency value F2
of motor 2
F13.21－F13.17 0.00Hz 0.01Hz ×
F13.20
V/f voltage value V2 of
motor 2
F13.22－F13.18 0V 1V ×
F13.21
V/f frequency value F1
of motor 2
0.00－F13.19 0.00Hz 0.01Hz ×
F13.22
V/f voltage value V1 of
motor 2
0－F13.20 0V 1V ×
F13.23
Torque boost of motor
2
0: Auto torque boost
0.1－30.0%
0.1% 0.1% ○
F13.24
Cut-off point used for
manual torque boost of
motor 2
0.0－50.0% (F13.04) 10.0% 0.1% ○
F13.25
Slip compensation gain
of motor 2
0.0－300.0% 100.0% 0.1% ○
F13.26
Slip compensation filter
time of motor 2
0.01－10.00s 0.10s 0.01s ○
F13.27
Slip compensation
limitation of motor 2
0.0%－250.0% 200.0% 0.1% ×
F13.28
Compensation
constant of motor 2
0.1－25.0s 2.0s 0.1s ○
F13.29 Reserved
F13.30
AVR function of motor
2
0: Disabled
1: Enabled all the time
2: Disabled in deceleration
process
1 1 ○
F13.31
Oscillation-suppression
mode of motor 2
0: Oscillation suppression is
dependent on the motor’s
exciting current component
1: Oscillation suppression is
dependent on the motor’s
torque current component
1 1 ○
F13.32
Oscillation-suppression
coefficient of motor 2
0－200 50 1 ○
F13.33 Reserved
