Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －137－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F13.34 Reserved
F13.35
Speed control
proportional gain 1 of
motor 2
0.1－200.0 20.0 0.1 ○
F13.36
Speed control integral
time 1 of motor 2
0.00－10.00s 0.20s 0.01s ○
F13.37
Speed control
proportional gain 2 of
motor 2
0.1－200.0 20.0 0.1 ○
F13.38
Speed control integral
time 2 of motor 2
0.00－10.00s 0.20s 0.01s ○
F13.39
Speed-loop PI
switching frequency 1
of motor 2
0.00－50.00Hz 10.00Hz 0.01Hz ○
F13.40
Speed-loop PI
switching frequency 2
of motor 2
0.00－50.00Hz 15.00Hz 0.01Hz ○
F13.41
Speed-loop integral
limitation of motor 2
0.0－200.0% (motor rated
current)
180.0% 0.1% ○
F13.42
Speed-loop differential
time of motor 2
0.00－1.00s
There is not the speed-loop
differential when F13.42 = 0
0.00s 0.01s ○
F13.43
Speed-loop output filter
time of motor 2
0.000－1.000s
When F13.43 = 0, the
speed-loop filter is disabled
0.020s 0.001s ○
F13.44 Reserved
F13.45 Reserved
F13.46
Motor torque limitation
when motor 2 is
forward
0.0－200.0% (motor rated
current)
180.0% 0.1% ×
F13.47
Motor torque limitation
when motor 2 is
reverse
0.0－200.0% (motor rated
current)
180.0% 0.1% ×
F13.48
Recreated torque
limitation when motor 2
is forward
0.0－200.0% (motor rated
current)
180.0% 0.1% ×
F13.49
Recreated torque
limitation when motor 2
is reverse
0.0－200.0% (motor rated
current)
180.0% 0.1% ×
F13.50 Reserved
F13.51 Reserved
F13.52 Reserved
Group F14 Reserved (refer to pages 81
－
81)
Group F15 Digital I/O Terminal Parameters (refer to pages 81
－
92)
