Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―138― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F15.00
DI1 terminal function
selection
0: Reserved
1: Inverter enabled
2: FWD function
3: REV function
4: Three-wire operation
mode
5,6,7: Frequency source
selection 1, 2, 3
8: AI to be the frequency
source
9,10: Run command source
selection 1,2
11: Terminal control mode to
be the run command source
12: External stop command
input
13－16: Multi-step frequency
terminal 1－4
17: Frequency ramp (UP)
18: Frequency ramp (DN)
19: Clearing auxiliary
frequency setting
20,21: Forward and reverse
jog 1 command control input
(JOGF1/ JOGR1)
22,23: Forward and reverse
jog 2 command control input
(JOGF2/ JOGR2)
24: Jog 1 command control
input
25: Jog 1 direction control
input (Remark: When select
20 and 21, the functions 24
and 25 are invalid)
26: Acc./Dec. time selection
terminals 1
27: Acc./Dec. time selection
terminals 2
28: Acc./Dec. mode selection
29: Acc./Dec. prohibition
30: Pausing PLC operation
31: Reset the stop status of
PLC operation
32: Pausing the process PID
33: Disabling the process
PID
0 1 ×
F15.01
DI2 terminal function
selection
0 1 ×
F15.02
DI3 terminal function
selection
0 1 ×
F15.03
DI4 terminal function
selection
0 1 ×
F15.04
DI5 terminal function
selection
0 1 ×
F15.05
DI6 terminal function
selection
0 1 ×
F15.06
DI7 terminal (option
terminal) function
selection
0 1 ×
F15.07
DI8 terminal (option
terminal) function
selection
0 1 ×
