Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －147－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
Group F19 Function-boost Parameters (refer to pages 99
105)
F19.00
Auxiliary frequency
setting source
selection
0: No auxiliary source
1: Digital setting 1 (the initial
value is set by F19.03 and
adjusted by and
keys on the display panel)
2: Digital setting 2 (the initial
value is set by F19.03 and
adjusted by terminals
UP/DN)
3: Digital setting 3 (the initial
value = 0, set by SCI direct
communication
4: AI analogue setting
5: Terminal pulse setting
6: Process PID output
0 1 ○
F19.01
Master/Auxiliary setting
calculation
0: Master setting + auxiliary
setting
1: Master setting – auxiliary
setting
2: MAX (master setting,
auxiliary setting)
3: MIN (master setting,
auxiliary setting)
4: Master setting + auxiliary
setting × master setting /
max. value of master setting
5: Master setting – auxiliary
setting × master setting /
max. value of master setting
0 1 ○
F19.02
Analogue auxiliary
setting coefficient
0.00－9.99 1.00 0.01 ○
F19.03
Initial value of digital
auxiliary frequency
0.00－F00.06 0.00 0.01Hz ○
F19.04
Control selection of
digital auxiliary
frequency
Units: Save selection at
power outage (Only when
F19.00 = 1 or 2 will F19.04
be enabled)
0: Not save auxiliary
frequency at power outage
1: The auxiliary frequency
will be saved to F19.03 at
power outage
Tens: Frequency disposal
when the inverter stops (Only
when F19.00 = 1 or 2 will
F19.04 be enabled)
0 1 ○
