Appendix C Communication Protocol Shenzhen Hpmont Technology Co., Ltd
―164― HD30 Series Inverters User Manual
Characteristics (Bit) Value Definition
00001B Unit is Hz
00010B Unit is A
00011B Unit is V
00100B Unit is rpm
00101B Unit is %
Reserved
Bit15－Bit13 Manufacturer reserved
7. Address Mapping
The inverter’s function parameters, control parameters and status parameters are all mapped as
MODBUS’s read-write register. And their group numbers are mapped as the higher bytes of
register address while the relationships are shown as below table.
High bytes of register
address
Group number
High bytes of register
address
Group number
0x00 F00 0x12 F18
0x01 F01 0x13 F19
0x02 F02 0x14 F20
0x03 F03 0x15 Reserved
0x04 F04 0x16 Reserved
0x05 F05 0x17 F23
0x06 F06 0x20 Reserved
0x07 F07 0x21 Reserved
0x08 F08 0x22 Reserved
0x09 F09 0x23 Reserved
0x0a F10 0x24 Reserved
0x0b F11 0x25 Reserved
0x0c Reserved 0x28 P00
0x0d F13 0x29 P01
0x0e Reserved 0x2a P02
0x0f F15 0x2b P03
0x10 F16 0x2c P04
0x11 F17 0x2d P05
0x18 U00
0x32 Control parameter group
0x33 Status parameter group
Their intergroup indexes are mapped as the lower bytes. Please refer to the instruction manual
for more details on function parameters F00
－
F23, P00
－
P05 and U00.
