HRC CBR600RR - Page 38

2-17
Racing Kit
6. Install the overflow catch tank to the intake air duct. 7. Route the radiator overflow hose properly referring to the illustration below,
then connect to the catch tank.
8. Fill the radiator with coolant and bleed air. Warm-up the engine and check
for coolant leaks.
Catch tank
(Optional)
Catch tank
(Racing kit)
Radiator overflow hose
(Racing kit)
Catch tank
(Racing kit)
