Racing Kit
2-22
Resister Installation
The 3P dummy connector is taped in the wire harness near the regulator/recti-
fier.
Remove the dummy connector, install the racing kit resister, and tape it onto
the wire harness.
If the resister is not installed, the ignition cut-off system is activated incorrect-
ly.
Turn Signal Switch Modification
Remove the turn signal switch from the handlebar.
Cut and remove the clutch switch wire from the turn signal switch and seal with
tape securely.
Resister
(racing kit)
Remove and discard
When using US type turn signal switch, the horn button functions as the hand
shifter.
Except US type switch, the horn button and passing switch functions as the
hand shifter.
