HRC CBR600RR - Radiator Set

3-21
1
2
3
4
5
6
7
8
9
•
•
•
•
•
•
•
•
06190-N1A-D00
19010-N1A-D01
19105-N1A-D00
19503-N1A-D00
19512-N1A-D00
19513-N1A-D00
19602-NF4-810
90651-NC8-000
95003-14081-10
RADIATOR SET .............................................................................................................
RADIATOR COMP. ........................................................................................................
STAY, RADIATOR LOWER ...........................................................................................
HOSE, RADIATOR R. ....................................................................................................
HOSE, RADIATOR L......................................................................................................
HOSE, OIL/C ..................................................................................................................
TANK, CATCH 250 ........................................................................................................
TY-LAP, 3.6 X 281 .........................................................................................................
VINYL-TUBE, 6 X 9 X 800...............................................................................................
Order 95003-14001-10M (6 x 9 x 1000)
F-11
Ref.
No.
Part No. Description Remarks
Radiator set
2010 CBR600RR
Block No.
THERMOSTAT
WATER PUMP
OIL
COOLER
4
5
8
7
2
9
8
6
3
1
1
1
1
1
1
1
1
2
1
Reqd. No.
