HRC CBR600RR - Wire Harness (2007 TYPE)

3-19
1
2
3
4
5
6
7
8
9
10
•
•
•
•
•
•
•
•
•
•
•
06304-N1A-D00
06304-N1A-J00
32100-MFJ-R00
32102-MFJ-R00
35160-MBW-Y02
35400-NL9 -000
37100-MFJ-R01
38770-MFJ-R01
38770-N1A-D00
38771-N1A-D00
38880-NL9 -C00
ELECTRIC SET (FIM) .....................................................................................................
ELECTRIC SET (ST).......................................................................................................
HARNESS, WIRE...........................................................................................................
WIRE, HARN FR. SUB...................................................................................................
SENSOR ASSY., BANK ANGLE ...................................................................................
RESISTER, COMP. ........................................................................................................
METER ASSY., COMBINATION ...................................................................................
UNIT ASSY. PGM-FI /IGN.............................................................................................
UNIT ASSY. PGM-FI /IGN.............................................................................................
CD-ROM, PGM-FI/IGN ..................................................................................................
UNIT ASSY., SERIAL I/F USB TYPE.............................................................................
06170-N1A-D00 (AIR FUNNEL SET) use with set.
F-9-1
Ref.
No.
Part No. Description Remarks
1
-
1
1
1
1
1
-
1
1
1
-
1
1
1
1
1
1
1
-
1
1
Wire harness
(2007 TYPE)
2010 CBR600RR
Block No.
5
4
8
7
1
3
9
10
2
6
STSS
Reqd. No.
2007
