Racing Kit
2-24
Air Funnel/Air Cleaner Element Replacement (2007 Model Kit)
The 2007 air funnel kit must be used with 2007 model ECU.
1. Remove the standard air cleaner element and air funnels.
2. Install the racing kit air funnels into their proper location according to each identification mark on the funnel.
3. Install the tongued washer and screws, then tighten the screws securely.
4. Bend the tabs of the tongued washer and lock the screws.
5. Install the racing kit air cleaner element.
Air cleaner elements
(racing kit)
Air funnel (#4)
(racing kit)
Air funnel (#1)
(racing kit)
Air funnel (#2)
(racing kit)
Air funnel (#3)
(racing kit)
Tongued washers
(racing kit)
