Service Information
1-8
Lubrication & Seal Points
Engine
Material Item Remarks
Honda 4-stroke motorcycle oil Piston/piston ring sliding surface
or an equivalent Clutch disc whole surface
API service classification: SG or Starter one-way clutch sliding surface
higher (except oils labelled as Crankpin bearing cap bolt threads and seating surface
energy conserving on the Flywheel bolt threads and seating surface
circular API service label) Clutch center lock nut threads and seating surface
JASO T903 STANDARD: MA Oil filter cartridge threads and O-ring
Viscosity: SAE 10W-30 Oil cooler bolt threads, sealing washer seating surface
Camshaft holder bolt threads and seating surface
Starter clutch mounting bolt threads and seating surface
Each gear teeth
Each O-ring
Each ball bearing and needle bearing
Other rotating and sliding surface
Engine inside
Molybdenum disulfide oil Main journal bearing sliding surface
(a mixture of engine oil Piston pin sliding surface
and molybdenum Crankpin bearing sliding surface
disulfide grease) Connecting rod small end I.D.
Crankshaft thrust surface
Camshaft lobe and journal surface
Valve stem (valve guide sliding surface
Valve lifter sliding surface
Oil pump drive sprocket guide sliding surface
Water pump shaft/thrust washer sliding surface
Clutch outer sliding surface
Clutch outer guide sliding surface
M3/4, C5, C6 shifter gear (shift fork grooves)
Starter reduction gear sliding surface
Starter idle gear shaft sliding surface
Cylinder head bolt threads and surface
