1-7
Service Information
Item
Thread/ Torque
Remarks
pitch N•m (kgf•m, lbf•ft)
Front master cylinder reservoir stopper M4 x 0.7 1.2 (0.1, 0.7)
plate bolt
Brake lever pivot bolt M6 x 1.0 1.0 (0.1, 0.7)
Brake lever pivot nut M6 x 1.0 6.0 (0.6, 4.3)
Brake master cylinder holder bolt M6 x 1.0 12 (1.2, 9)
Front brake caliper assembly bolt M8 x 1.25 22 (2.2, 16) Apply locking agent
Front brake caliper mounting bolt M10 x 1.25 45 (4.6, 33) ALOCK bolt; replace with a new one
Front brake reservoir stay bolt M6 x 1.0 12 (1.2, 9)
Rear master cylinder push rod lock nut M8 x 1.25 18 (1.8, 13)
Rear brake reservoir cap screw M4 x 0.7 1.5 (0.2, 1.4)
Rear master cylinder mounting bolt M6 x 1.0 10 (1.0, 7)
Rear master cylinder reservoir tank M6 x 1.0 12 (1.2, 9)
mounting bolt
Rear brake hose screw M4 x 0.7 1.5 (0.2, 1.4)
Front brake caliper pad pin M10 x 1.25 15 (1.5, 11)
Rear brake caliper pad pin M10 x 1.25 15 (1.5, 11)
Brake hose oil bolt M10 x 1.25 34 (3.5, 25)
Front brake hose clamp bolt M6 x 1.0 9.0 (0.9, 6.5)
Front brake hose clamp nut M6 x 1.0 10 (1.0, 7)
Brake hose oil bolt M6 x 1.0 10 (1.0, 7)
