Service Information
1-6
Item
Thread/ Torque
Remarks
pitch N•m (kgf•m, lbf•ft)
Seat rail mounting bolt M10 x 1.25 54 (5.5, 40) 10 x 45
Seat rail mounting bolt M10 x 1.25 54 (5.5, 40) 10 x 32
Fuel pump mounting nut M6 x 1.0 12 (1.2, 9)
Bank angle sensor mounting screw M4 x 0.7 1.5 (0.2, 1.4)
Fuel tank mounting bolt M8 x 1.25 30 (3.1, 22)
IAT sensor mounting screw M5 1.1 (0.1, 0.7) 5 x 16 tapping screw
MAP sensor mounting screw M5 1.1 (0.1, 0.7) 5 x 16 tapping screw
ECM set plate screw M5 0.7 (0.07, 0.6) 5 x 20 tapping screw
Front brake disc bolt M6 x 1.0 20 (2.0, 1.4) ALOCK bolt; replace with a new one
Front axle bolt M14 x 1.5 59 (6.0, 43)
Front axle holder bolt M8 x 1.25 22 (2.2, 16)
Fork socket bolt M10 x 1.25 34 (3.5, 25)
Fork bolt M44 x 1.5 34 (3.5, 25)
Handlebar pinch bolt M6 x 1.0 10 (1.0, 7)
Top bridge pinch bolt M8 x 1.25 22 (2.2, 16)
Bottom bridge pinch bolt M8 x 1.25 27 (2.8, 20)
Steering stem adjusting nut M26 x 1.0 25 (2.5, 18)
Steering stem adjusting nut lock nut M26 x 1.0 –
Steering stem nut M24 x 1.0 103 (10.5, 76)
Steering damper mounting bolt M6 x 1.0 10 (1.0, 7)
Second arm nut M6 x 1.0 12 (1.2, 9)
Rear brake disc bolt M8 x 1.25 42 (4.3, 31) ALOCK bolt; replace with a new one
Final driven sprocket nut M10 x 1.25 64 (6.5, 47)
Rear axle nut M22 x 1.5 113 (11.5, 83)
Rear shock absorber mounting nut M10 x 1.25 44 (4.5, 33) U-nut
Shock arm nut (swingarm side) M10 x 1.25 44 (4.5, 33) U-nut
Drive chain case bolt M6 x 1.0 12 (1.2, 9)
Drive chain slider bolt M6 x 1.0 9.0 (0.9, 6.5) ALOCK bolt; replace with a new one
Swingarm pivot adjust bolt M30 x 1.0 12 (1.2, 9) Apply oil to the threads
Swingarm pivot lock nut M30 x 1.0 64 (6.5, 47)
Swingarm pivot nut M18 x 1.5 93 (9.5, 69)
Shock arm nut M10 x 1.25 44 (4.5, 33) U-nut
Frame
