1-5
Service Information
Item
Thread/ Torque
Remarks
pitch N•m (kgf•m, lbf•ft)
Starter motor terminal nut M6 x 1.0 10 (1.0, 7)
Oil pressure switch PT1/8 12 (1.2, 9) Apply sealant to the thread
Oil pressure switch terminal screw M4x 0.7 2 (0.2, 1.4)
Neutral switch M10 x 1.25 12 (1.2, 9)
Exhaust pipe stud bolt M8 x 1.25 – See illustration below
Insulator band Exhaust pipe stud Oil filter boss
12 ± 1 mm
45.5 ± 10.5 mm
16.5 ± 0.5 mm
