HRC CBR600RR - Front Fork

3-10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
•
•
•
•
•
•
•
•
•
•
•
•
51400-MFJ-R11
51401-MEE-R21
51401-NL3-921
51402-NL3-921
51403-NL3-921
51403-MEE-D01
51404-MFJ-R01
51406-MFJ-R01
51410-MFJ-D01
51412-MB4-003
51414-KCR-003
51415-KCR-003
51420-MFJ-R01
51430-MFJ-R11
51447-KA4-711
51450-MFJ-R01
51455-MEE-D01
51490-MEE-D01
51500-MFJ-R11
51520-MFJ-R01
FORK ASSY., R. FRONT ...............................................................................................
SPRING, FR. FORK (0.95) .............................................................................................
SPRING, FR. FORK (0.90) .............................................................................................
SPRING, FR. FORK (1.00) .............................................................................................
SPRING, FR. FORK (1.05) .............................................................................................
COLLAR, SPRING ..........................................................................................................
COLLAR B, SPRING ......................................................................................................
STOPPER, SPRING SEAT .............................................................................................
TUBE, OUTER ................................................................................................................
RING, BACK UP..............................................................................................................
BUSH, GUIDE.................................................................................................................
BUSH, SLIDER ...............................................................................................................
PIPE ASSY., R. SLIDER .................................................................................................
DAMPER COMP., FR.....................................................................................................
RING, OIL SEAL STOPPER ............................................................................................
BOLT COMP., FR. FORK ...............................................................................................
RING, STOPPER.............................................................................................................
SEAL SET, FR. FORK .....................................................................................................
FORK ASSY., L. FRONT................................................................................................
PIPE ASSY., L. SLIDER .................................................................................................
No mark
0.90
1.00
1.05
F-3
Ref.
No.
Part No. Description Remarks
1
2
(2)
(2)
(2)
2
2
2
2
2
2
2
1
2
2
2
2
2
1
1
Front fork
2010 CBR600RR
Block No.
12
5
6
14
15
16
10
17
18
19
20
21
11
1
2
3
13
4
22
7
8
9
Reqd. No.
