1-9
Service Information
Material Item Remarks
Multi-purpose grease Timing hole cap threads
Each oil seal lip
Three bond 1207B Crankcase mating surface
Oil pan mating surface
Crankcase/cover mating surface
Oil pressure switch threads
ACG cover wire grommet
Right crankcase cover wire grommet
Cylinder head semi-circular portion
Locking agent Cam pulse generator rotor bolt threads
Oil pump driven sprocket bolt threads Coating width: 6.5 ± 1 mm
Shift drum bearing set plate bolt threads Coating width: 6.5 ± 1 mm
Mainshaft bearing set plate bolt threads Coating width: 6.5 ± 1 mm
Cam sprocket bolt threads Coating width: 6.5 ± 1 mm
Shift drum center bolt threads Coating width: 6.5 ± 1 mm
Cam chain tensioner A pivot bolt threads Coating width: 6.5 ± 1 mm
Cam chain tensioner B pivot bolt threads Coating width: 6.5 ± 1 mm
Shift drum stopper arm pivot bolt threads Coating width: 6.5 ± 1 mm
Oil jet pipe mounting bolt threads Coating width: 6.5 ± 1 mm
Oil level plate bolt threads Coating width: 6.5 ± 1 mm
Oil pipe A/B mounting bolt threads Coating width: 6.5 ± 1 mm
AICV reed valve cover threads
Oil filter boss threads (crankcase side) Coating width: 6.5 ± 1 mm
