- 27 -
1. Place the rivet on the mandrel.
2. Press start buon and thread on blind rivet nut. While doing so hold the blind rivet nut
as far forward as possible and do not reach into the opening.
3. Hold the start buon down unl the blind rivet nut has been completed threaded on;
the tool stops automacally.
4. Guide the rivet into the hole provided and let the tool process the blind rivet nut by
actuang the start buon.
5. Release the start buon aer the set process has ended.
6. The tool will automacally spin o aer reaching the programmed set stroke or set
force.
DANGER
The nose assembly is a moving component that heats up during the process
and can cause crushing.
• Under no circumstances should you touch parts of the nose assembly
during the process.
1 32
4 4 54
