5. In case the instrument detects a voltage >3V at its
terminals E and C, it does not carry out the test, gives out
a long sound and displays the message “VInput > 3V”.
IVCK 15/10 – 18:04
Remote U. not active
VPN VPE VNE
0V 0V 0V
VInput > 3V
1000V 1.00M 2 - - - 
VTest ISO RPE
><
6. In case the instrument detects a current <0.1A while
measuring Isc current, the message to the side appears
on the display. Check the connections of the instrument
to the circuit being tested.
IVCK 15/10 – 18:04
Remote U. not active
VPN VPE VNE
0V 0V 0V
Isc < 0.1A
1000V 1.00M 2 - - - 
VTest ISO RPE
><
7. In case the instrument detects a blown fuse while
measuring Isc current, the message to the side appears
on the display. Please contact HT’s After-sales Service.
IVCK 15/10 – 18:04
Remote U. not active
VPN VPE VNE
0V 0V 0V
Blown fuse
1000V 1.00M 2 - - - 
VTest ISO RPE
><
8. In case no recording has been activated on remote unit
SOLAR03, the message to the side is shown on the
display. Check the status of the remote unit SOLAR03
IVCK 15/10 – 18:04
Front
Irr. - - - W/m2
Temp. - - - °C
SOLAR03 23051203
Module: SUNPOWER318WTH
VPN VPE VNE
1480V 740V -740V
Rem.Unit not connected
1000V 1.00M 2 0.25
VTest ISO RPE
><
