LTE TDD B2268H
User Guide
1 Introduction
Issue 01 (2014-01-15)
Copyright © Huawei Technologies Co., Ltd.
5
Table 1-1 LED Descriptions (From Left To Right)
LED
COLOR
STATUS
DESCRIPTION
PWR/SYS
Green
On
The LTE Device is receiving power and ready for
use.
Blinking
The LTE Device is booting up.
Red
On
The LTE Device detected an error while
self-testing, or there is a device malfunction.
Blinking
The LTE Device is upgrading the firmware.
Off
The LTE Device is not receiving power.
LINK
Green
On
The LTE Device has an LTE connection on the
WAN.
Blinking
The LTE Device is searching for a frequency
channel or is performing network entry.
Off
The LTE Device does not have an LTE connection
on the WAN.
LTE RSSI
Green
(RSSI_1,
RSSI_2,
RSSI_3,
RSSI_4,
RSSI_5)
No Signal
LEDS
There are 5 signal LEDs to show the Received
Signal Strength Indication (RSSI) of the LTE
radio connection.
There is no LTE connection.
Refer Table 1-2 LTE Signal Strength LED Definition
Please note the ODU presents the same LED behavior as IDU.
WLAN/
WPS
Green
On
The wireless network is activated and is operating
in IEEE 802.11 "b", "g" or "n" mode.
Blinking
The LTE Device is communicating with other
wireless clients.
Orange
Blinking
The LTE Device is setting up a WPS connection.
Off
The wireless network is not activated.
PHONE
Green
On
A SIP account is registered for the phone port.
Blinking
A telephone connected to the phone port has its
receiver off of the hook or there is an incoming
call.
Orange
On
A SIP account is registered for the phone port and
there is a voice message in the corresponding SIP
account.
Blinking
A telephone connected to the phone port has its
receiver off of the hook and there is a voice
message in the corresponding SIP account.
Off
The phone port does not have a SIP account
