Figure 14-28 Installing a cabinet
(1) Gasket with an oblong hole
Step 7 Use two bolts to secure the fastening bar on the wall, as shown in Figure 14-29.
NOTE
When a cabinet is installed on the wall, grease must be applied. For details, see 14.8.3 Applying Grease.
Figure 14-29 Securing a fastening bar
DBS3900 (Ver.B)
Installation Guide
14 Indoor Scenario with DC Power Supply (BBU Installed
Indoors and RRU Powered Outdoors)
Issue 06 (2011-09-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
520
