No. Check Item Method
12 The power cables and ground cable are securely
connected in compliance with regulations. Ground cable
lugs are protected with spring washers on flat washers.
Observe
13 The power cables and ground cable are separated from
the signal cables.
Observe
14 The power cables and ground cable are routed straightly
and bundled neatly. Sufficient slack is left at the bent
part of the cables.
Observe
15 Optical fibers routed out of the cabinet are protected.
For example, they are routed in a corrugated pipe or
trough.
Observe
16 The bend radius of optical fibers is 20 times larger than
their diameter. Generally, the bend radius is larger than
40 mm.
Measure
17 Optical fibers are bundled neatly using binding tape
with suitable force.
Observe
18 No signal cables are routed near the heat vents on the
cabinet.
Observe
19 Cables in the cabinet do not cross each other and cables
outside the cabinet are bundled.
Observe
