7 Connecting a Switch
About This Chapter
7.1 Connecting Power Cables
7.2 Connecting Ethernet Cables
7.3 Connecting Optical Fibers
7.4 Connecting Copper Cables
7.5 Connecting Stack Cables
7.1 Connecting Power Cables
Context
Determine the types of power module and power cable based on the power supply facility
used in your equipment room:
l To connect to an AC power outlet, the switch must have a built-in AC power supply unit
or use a pluggable AC power module, which must be connected using an AC power
cable complying with local standards.
l To connect to an AC power distribution unit (PDU), the switch must have a built-in AC
power supply unit or use a pluggable AC power module, which must be connected using
a C13 straight female to C14 straight male AC power cable.
l To connect to a DC power distribution box, the switch must have a built-in DC power
supply unit or use a pluggable DC power module, which must be connected using DC
power cables.
DANGER
To avoid electric shock, do not connect power cable while the power is on.
S2700&S3700&S5700&S6700 Switch
Hardware Installation and Maintenance Guide
7 Connecting a Switch
Issue 13 (2017-11-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
52
