LED Description
RUN/ALM: Running
LED
Red: on for 0.25s and off for
0.25s repeatedly
The device is starting up.
Green: on for 1s and off for 1s
repeatedly
The device works in the normal
state.
Red: on The device is faulty.
SYNC: Clock
synchronization LED
Green: on Clock synchronization success
or the system is not configured
clock source.
Red: on Clock synchronization fails.
LED of the POTS port Green: on At least one service port is busy.
LED: off All the ports are idle.
LED of the FE electrical
port
Green: on A connection is set up on the
port.
LED: off No connection is set up on the
port.
Green: blinking The port is transmitting or
receiving data.
A.2 Making Cables and Connectors
This topic describes how to make the power cable, ground cable, and network cable.
A.2.1 Making Console-Ethernet Integrated Cables
When a device is running, the serial port on the device can be used as a maintenance serial port
and a network port at the same time. Therefore, a console-Ethernet integrated cable is needed
to support the concurrent use of the serial port. The console-Ethernet integrated cable is a type
of non-standard cable, which must be made on site as required.
Wire Sequence of a Console-Ethernet Integrated Cable
Figure A-2 shows the wire sequence of a console-Ethernet integrated cable.
