For the network cables that connect to the hubs, servers, or agents of the VAS devices, the
information on the labels is provided according to the actual conditions.
l For the cable from the hub to the server, specify the cabinet number and subrack number
where the hub is located, and specify the serial number on the hub. Specify the cabinet
number and subrack number where the server is located. For a stand-alone server, specify
the specific position of the server.
l For the cable from the hub to the agent, specify the serial number of the network port on
the agent end. The cabinet number and the subrack number should be the same as the cabinet
number and the subrack number described in Table A-10.
l For a stand-alone hub that is not installed in any subrack or cabinet, specify its recognizable
position.
Specify the serial number on the hub, the network port number of the agent and the position of
the stand-alone server according to the actual conditions.
Example of the Label
Figure A-56 shows the label for the network cable.
Figure A-56 Example of the label for the network cable
l "A01-03-10-05" indicates that one end of the network cable is connected to Ethernet port
05, slot 10, subrack 03 of the cabinet in row A, column 01.
l "B02-03-12" indicates that the other end of the network cable is connected to Ethernet port
12, subrack 03 of the cabinet in row B, column 02. The slot number is not specified.
A.3.7 Labels for Optical Fibers
This topic provides information on labels and example of labels for optical fibers. There are two
types of labels that are used for optical fibers: one for the optical fiber connecting two cabinets
and one for the optical fiber connecting the cabinet to the ODF.
Meaning of the Label for Optical Fiber Connecting Two Cabinets
Table A-11 describes the information on the label for the optical fiber connecting two cabinets.
Table A-11 Information on the label for the optical fiber connecting two cabinets
Content
Meaning Example
MN-B-C-D-R/
T
MN: Cabinet number A01 indicates the first cabinet in row A.
SmartAX MA5612 Multi-service Access Module
