Connect cables between the battery modules and then connect the cables to the battery
management module.
Communications cables between the battery modules and the battery management module
are preinstalled inside the cabinet.
Figure 3-21 Installing battery communications cables
Step 5 Open the battery terminal protective cover and install battery copper bars and cables.
