5 Operations
5.1 Powering On Batteries
Prerequisites
Turn on the ready switch on the battery management module.
Procedure
Step 1 On the UPS LCD screen, set System Info > Settings > Battery Settings > Battery Type to
Lithium battery.
Upgrade the UPS software to the version that supports lithium battery connection. See
UPS5000 The Relationship of Software Version to check the version number.
Thres. of low batt. volt. over dry contact (V/cell): If you set Batt. Volt. Below
Threshold for an output dry contact and the battery voltage is lower than this threshold,
the output dry contact will output signals accordingly.
Step 2 Press and hold the POWER ON/OFF button on the battery management module for more than
2s. The green indicator of the battery management module blinks at 4 Hz.
The BCB off alarm is displayed on the UPS LCD and SmartLi LCD. No action is required.
After the battery circuit breaker is closed, the alarm is automatically cleared.
After the battery management module is started, the green indicator is on for 1s and then
off for 4s, and the yellow indicator is steady on.
If multiple SmartLi cabinets are combined, press and hold the POWER ON/OFF button on
each battery management module of the cabinets one by one for more than 2s.
Step 3 Set the language, time, date, network parameters, and system parameters on the Settings
Wizard screen
