SmartLi
User Manual
9 Technical Specifications
Issue 04 (2019-09-16)
Copyright © Huawei Technologies Co., Ltd.
95
9 Technical Specifications
Table 9-1 Physical specifications
Item
Specifications
Cabling
Cables can be routed in and out from the top.
IP rating
IP20
Dimensions (H x W x D)
2000 mm x 600 mm x 850 mm
Communication
Supports RS485, FE, and CAN.
Weight
< 750 kg
Circuit breaker
specifications
690 V AC/750 V DC, 500 A, 4P
Fuse specifications
Each battery string is configured with an 800 V DC 250 A
fuse.
Table 9-2 Environmental specifications
Item
Specifications
Operating temperature
0°C–40°C
Storage temperature
0°C–45°C
Relative humidity
5%–95% RH (non-condensing)
Altitude
0–4000 m
Table 9-3 Safety and EMC
Item
Specifications
Safety regulations
IEC/EN62619
EMC
EN62040-2
