Huawei SUN2000-33KTL User Manual

SUN2000-(33KTL, 40KTL)
User Manual
7 User Interface
Issue 03 (2015-12-01)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
73
Step 4 Import the boot script file to a computer.
Step 5 Replace the boot script file in the upgrade package with the one generated by the SUN2000
local commissioning tool.
Step 6 Copy the extracted files to the root directory of the USB flash drive.
Step 7 Connect the USB flash drive to the USB port. The system automatically identifies the USB
flash drive and executes all commands specified in the boot script file. View the LED
indicator to determine the operating status.
Verify that the ciphertext in the boot script file matches the login password of the SUN2000
APP; otherwise, after you insert the USB flash drive for five consecutive times, the user
account will be locked for 10 minutes.
Table 7-4 Indicator status
Indicator
Status
Meaning
Off
There is no operation with
a USB flash drive.
Blinking green slowly (on for 1s and
then off for 1s)
There is an operation with
a USB flash drive.
Blinking green fast (on for 0.125s
and off for 0.125s)
An operation with a USB
flash drive has failed.
Steady green
An operation with a USB
flash drive is successful.
Step 8 (Optional) The system automatically restarts when the upgrade is completed. All indicators
are off during the restart. After the restart, the preceding indicator is blinking green slowly (on
for 1s and then off for 1s) for 1 minute until it becomes steady on, which indicates that the
upgrade is successful.
The upgrade of the SUN2000 can also be completed through the Inverter Upgrade in the SUN2000
APP. For details, see SUN2000 APP User Manual.
----End
7.2 Operations with a SmartLogger
For operations with a SmartLogger, see SmartLogger1000 User Manual.

Huawei SUN2000-33KTL Specifications

General

Purpose	Solar panel
Efficiency	98.6 %
Output power	30000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, IEC 62116
Input voltage	250 - 1100 V
Output current	43.3 A
Output voltage	230/400 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
