Huawei SUN2000-33KTL User Manual

SUN2000-(33KTL, 40KTL)
User Manual
1 Safety Precautions
Issue 03 (2015-12-01)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2

Open the maintenance compartment door before cable connection. Do not touch any
other components inside the chassis when connecting AC power cables and
communications cables.
Electrical Connection
Before connecting cables to the SUN2000, ensure that the SUN2000 is securely positioned
and not damaged in any way. Otherwise, electrical shock or fire may occur.

Shield the PV modules with opaque cloth before connecting cables to the SUN2000.

Ensure that all electrical connections comply with local electrical standards.

Obtain approval from the local power supply department before using the SUN2000 to
generate electricity in grid-tied mode.

Ensure that the cables to the solar power system are properly connected and insulated
and meet specifications.
Operation
High voltage may cause electrical shock and death during operation. Strictly comply with the
safety precautions in this document and associated documents when operating the SUN2000.

Do not touch parts of the SUN2000 because the enclosure and heat sinks are extremely
hot when the SUN2000 is in operation and touching these parts can cause severe burns
and personal injury.

Follow local laws and regulations when operating the SUN2000.
Maintenance and Replacement
High voltages may cause electrical shocks and serious injuries during the SUN2000 operation.
Therefore, before maintenance, power off the SUN2000 and strictly comply with the safety
precautions in this document and associated documents to operate the SUN2000.

Before performing maintenance tasks, power off the SUN2000 based on the description
in 6.2 Powering Off the SUN2000 and wait for at least 5 minutes.

Place temporary warning signs or erect fences to prevent unauthorized access to the
maintenance site.

Rectify any faults that may compromise the SUN2000 security performance before
restarting the SUN2000.

Huawei SUN2000-33KTL Specifications

General

Purpose	Solar panel
Efficiency	98.6 %
Output power	30000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, IEC 62116
Input voltage	250 - 1100 V
Output current	43.3 A
Output voltage	230/400 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
