Huawei SUN2000-33KTL User Manual

SUN2000-(33KTL, 40KTL)
User Manual
2 Overview
Issue 03 (2015-12-01)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
2 Overview
2.1 Introduction
Function
The SUN2000-33KTL/40KTL is a three-phase grid-tied PV string inverter that converts the
DC power generated by PV strings into AC power and feeds the power into the power grid.
Models
Figure 2-1 shows a model number of the SUN2000-33KTL/40KTL, using SUN2000-33KTL
as an example.
Figure 2-1 Model number description
Table 2-1 lists all models of the SUN2000-33KTL/40KTL and their rated output power.
Table 2-1 SUN2000 models and rated output power
Model
Rated Output Power
SUN2000-33KTL
30 kW
SUN2000-40KTL
36 kW
Network Application
The SUN2000-33KTL/40KTL applies to grid-tied PV power systems for commercial rooftops
and large power stations. Typically, a grid-tied PV power system consists of PV strings,

Huawei SUN2000-33KTL Specifications

General

Purpose	Solar panel
Efficiency	98.6 %
Output power	30000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, IEC 62116
Input voltage	250 - 1100 V
Output current	43.3 A
Output voltage	230/400 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
