Huawei SUN2000-33KTL User Manual

SUN2000-(33KTL, 40KTL)
User Manual
8 Maintenance
Issue 03 (2015-12-01)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
80
Alarm ID
Alarm
Name
Alarm
Severity
Causes
Measures
305
Frequency
Abnormal
Major
The actual frequency of the
grid is higher than or less than
the required value for the local
grid.
1. If the alarm occurs accidentally,
possibly the power grid is
abnormal accidentally. The
SUN2000 automatically recovers
to the normal operating status
after the fault is rectified.
2. If the alarm occurs repeatedly,
check whether the grid frequency
is within the allowable range. If
no, contact the local power
operator. If yes, change the grid
overfrequency and
underfrequency protection points
on the SUN2000 APP, data
collector, or NMS after obtaining
approval from the local power
operator.
313
Low Array
Insulation
Resistance
Major
The insulation resistance
against the ground for PV
strings is less than the
minimum value. The possible
causes are as follows:

A short circuit exists
between PV strings and
protection ground.

PV strings are installed in a
permanently moist
environment.
1. Check the insulation resistance
against the ground for the PV
strings. If a short circuit has
occurred, rectify the fault.
2. If the insulation resistance
against the ground is less than the
default value in a rainy
environment, set Insulation
resistance protection on the
SUN2000 APP, data collector, or
NMS.
318
Residual
Current
Abnormal
Major
The insulation resistance
against the ground at the input
side decreases during
SUN2000 operation, which
causes excessively high
residual current.
1. If the alarm occurs accidentally,
possibly the external circuits are
abnormal accidentally. The
SUN2000 automatically recovers
to the normal operating status
after the fault is rectified.
2. If the alarm occurs repeatedly or
lasts a long time, check whether
the insulation resistance against
the ground of PV strings is too
low.
321
Cabinet
Over-Tem
p
Major

The SUN2000 is installed
in a place with poor
ventilation.

The ambient temperature is
too high.

The internal fan is not
working.
Check whether the ambient
temperature of the SUN2000
exceeds the upper limit. If yes,
improve ventilation to decrease the
temperature.

Huawei SUN2000-33KTL Specifications

General

Purpose	Solar panel
Efficiency	98.6 %
Output power	30000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, IEC 62116
Input voltage	250 - 1100 V
Output current	43.3 A
Output voltage	230/400 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
