Huawei TaiShan 200 2280 - Rear Panel Components

Silkscr
een
Indicator/
Button
State Description
UID
button/
indicator
The UID button/indicator helps identify and locate a
device.
UID indicator:
● O: The device is not being located.
● Blinking blue (blinking 255 seconds): The device has
been located and is
dierentiated from other devices
that have also been located.
● Steady blue: The device is being located.
UID button:
● You can turn on, turn
o, or blink the UID indicator by
pressing the UID button on the panel or by using the
iBMC CLI or WebUI.
● You can press this button to turn on or
o the UID
indicator.
● You can press and hold down this button for about 5
seconds to reset the iBMC.
Health
indicator
● Steady green: The server is operating properly.
● Blinking red at 1 Hz: A major alarm has been
generated on the server.
● Blinking red at 5 Hz: A critical alarm has been
generated on the server.
FlexIO
presence
indicators
(1 and 2)
● 1 and 2: The numbers 1 and 2 respectively represent
FlexIOs 1 and 2.
● Steady green: The FlexIO is properly connected.
● O: The FlexIO cannot be detected.
2.3 Rear Panel Components
Figure 2-10 shows the components on the rear panel of the server.
TaiShan 200 Server
Maintenance and Service Guide (Model 2280) 2 Components
Issue 04 (2020-01-16) Copyright © Huawei Technologies Co., Ltd. 10
