OPERATION
16
Problem
The chain wheel orientation needs to be changed.
Solution Change the Chain Guide Orientation
■
Remove the screw
and washer from the
bracket. Be sure to keep
the nut in place. A spare
screw has been provided
if needed.
■
Remove the chain wheel by pulling it up from the base of the bracket. Turn
the chain wheel to the new orientation and press back onto the base.
■
Install the washer and the screw.
■
Replace the bracket cover.
Problem
The shade will not fit into the installation brackets.
Solution
Check that the installation brackets are level and aligned. Adjust and/or shim
to level if necessary.
NOTE: If you have a cassette: Check that the headrail is completely inserted
into the installation brackers. See “Install the Shade— Cassette” on
page 11.
Metal
Standard
Outside Mount Orientation
Turn to Change Orientation to Inside Mount
Designer Metal
Right Control Left Control
Standard
Inside Mount Orientation
Turn to Change Orientation
to Outside Mount
Designer
Metal
Standard
NOTE: Arrow indicates
downward shade operation.
