English - 18
Software type 450X
MAIN 7.02.00
HMI 6.00.00
SUB 6.00.00
COM 6.00.00
U.SONIC 1.00.00
SW Prod.
2 Special menu functions
2.1 Quick Info
Quick Info is a display mode where you can quickly
see information about program versions, battery,
loop signals, sensors and operating history.
When the start page or the main menu is displayed:
Press and hold down the 0 key for 2 seconds to ac-
cess the Quick Info function.
Quick Info is divided into Info and History. Info dis-
plays current status and History displays operating
history regarding messages and saves search times.
Browse among the menus using Arrow down and
press OK to select the required function. Keep the
BACK button depressed for 2 seconds to exit the
Quick Info function and go to the main menu.
2.1.1 Operate with the cover open
For a number of the display modes below, for in-
stance Loop, it may be necessary to make a note of
the values while the mower is in operation. To do this,
the mower cover must be open while it operates.
1. Select one of the display modes shown in
Quick Info.
2. Start the mower by pressing the START
button.
3. Instead of closing the cover as is normal,
press in the cover locking devices with the
cover open.
4. The mower will now run as normal but the
quick information can be read at all times in
the display.
5. The mower can be stopped as normal by
pressing the stop button.
2.1.2 Info
The Info - General - SW display mode shows:
• Software type: Model for which the main
program is intended.
• MAIN: Version of the main program.
• HMI: HMI (Human Machine Interface)
program version.
• SUB: Subdevice program version
2. SPECIAL MENU FUNCTIONS
