Husqvarna AUTOMOWER 430X Technical Manual

English - 79
5.26 Replacing the contact strips,
charging station
When the mower’s battery does not recharge or the
mower cannot contact the charging station, this may
be due to worn contact strips in the charging station.
The contact strips should be replaced when black-
ened or oxidized. Also check the charging strips on
the mower, see 5.6 Replacing the charging strips on
page 64.
1. Dismantle the cover from the charging
station, see 5.3 Dismantling the charging
station on page 63.
2. Unscrew the 2 screws (Torx 20) securing
the cable lugs and contact strips.
3. Replace the contact strips. Also check that
the cable lugs are undamaged and are not
oxidized.
4. Fit the contact strips, the cable lugs and
charging station cover.
NB! Make sure that the contact strip can
move freely and that it springs back.
5.27 Assembling the sealing strip
Alternative 1 - Clockwise
Start by laying one end of the sealing strip in line
with the marking on the chassis.
Continue laying the sealing strip clockwise around
the chassis half.
Lay the other end of the sealing strip above the rst
end and then out of the channel. Fasten with retain-
er on the bottom.
5. REPAIR INSTRUCTIONS

Husqvarna AUTOMOWER 430X Specifications

General

Product Name	Husqvarna AUTOMOWER 430X
Category	Lawn Mower
Cutting Width	24 cm
Cutting Height Min	20 mm
Cutting Height Max	60 mm
Battery Type	Li-ion
Typical Charging Time	50 min
Maximum Incline Within the Working Area	45 %
Cutting System	3 pivoting razor blades
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	No
Battery Voltage	18 V
Weight	13.2 kg
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
