Husqvarna AUTOMOWER 430X Technical Manual

English - 64
5.5 Changing the top cover (450X)
1. Dismantle the body, see 5.2.1 Dismantling
the body on page 59.
2. Unscrew the 8 screws (Torx 20) from the
underside of the body.
3. Carefully snap the top cover loose from
the body.
4. Snap on the new top cover.
5. Fit the screws and then the body.
5.6 Replacing the charging strips
When the mower’s battery does not recharge this
may be due to worn charging strips in the mower.
The charging strips should be replaced when
blackened or if there is oxide. Also check the con-
tact strips in the charging station, see
5.26 Replacing the contact strips, charging station
on page 79.
1. Dismantle the body, see 5.2.1 Dismantling
the body on page 59.
2. Remove the screw (Torx 20) retaining the
holder with the charging strips underneath
the body.
3. Dismantle the holder.
4. Dismantle the charging strips with
associated charging cable.
5. Assemble the new charging strip with
associated charging cable.
6. Assemble the holder and tighten the
screw with the recommended tightening
torque. Refer to 5.28 Mounting screws on
page 80
7. Then assemble the body, see
5.2.6 Assembling the body on page 62
5. REPAIR INSTRUCTIONS

Husqvarna AUTOMOWER 430X Specifications

General

Product Name	Husqvarna AUTOMOWER 430X
Category	Lawn Mower
Cutting Width	24 cm
Cutting Height Min	20 mm
Cutting Height Max	60 mm
Battery Type	Li-ion
Typical Charging Time	50 min
Maximum Incline Within the Working Area	45 %
Cutting System	3 pivoting razor blades
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	No
Battery Voltage	18 V
Weight	13.2 kg
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
