Husqvarna AUTOMOWER 430X Technical Manual

English - 78
5.24 Changing and regreasing
lower front wheel bearing
1. Dismantle the body, see 5.2.1 Dismantling
the body on page 59.
2. Dismantle the front wheel by loosening the
3 screws on the side of the wheel and then
splitting the wheel.
3. Remove the lock washer from the axle.
4. Remove the washer, ball bearing and the
inner front wheel half from the axle.
5. Apply grease to both ball bearings.
Ret the inner front wheel half, ball bearing
and washer.
6. Fit a new lock washer onto the axle. NB! Do
not reuse the old washer as this will not give
a satisfactory lock after being removed from
the axle.
7. Apply grease to the outer front wheel half
before assembling.
5.25 Replacing the circuit board,
charging station
1. Dismantle the cover from the charging
station, see 5.3 Dismantling the charging
station on page 63.
2. Loosen all contacts from the circuit board.
3. Snap off the circuit board from the charging
tower by carefully turning back the locking
edges.
4. Fit the new circuit board.
5. Reconnect all connectors to the circuit board.
6. Assemble the charging station in reverse order.
5. REPAIR INSTRUCTIONS

Husqvarna AUTOMOWER 430X Specifications

General

Product Name	Husqvarna AUTOMOWER 430X
Category	Lawn Mower
Cutting Width	24 cm
Cutting Height Min	20 mm
Cutting Height Max	60 mm
Battery Type	Li-ion
Typical Charging Time	50 min
Maximum Incline Within the Working Area	45 %
Cutting System	3 pivoting razor blades
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	No
Battery Voltage	18 V
Weight	13.2 kg
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
