5. Repair instructions
™
5.19 Tightening torques
Table 10: Tightening Torques
Joint Part no. Mounting
elements
(Tool)
Notes Part no. Assembly
torque
(Nm)
Remarks
Chassis, lower
Holder,
battery
535 13 39-01 Screw
(Torx-20)
2 535 13 03-14 1.0
Wheel motor,
complete
535 13 72-02 Screw
(Torx-20)
8 535 13 03-16 1.0
Drive wheel,
complete
535 13 60-02 Screw
(Hex-5)
2 535 13 94-01 8-10 Torque wrench
Locking
spring
535 12 24-01 Screw
(Torx-20)
1 535 13 03-14 1.0
Speaker,
complete
535 12 57-01 Screw
(Torx-20)
2 535 13 03-10 1.0
Control box,
complete
544 23 06-01 Screw
(Torx-20)
4 535 13 03-10 1.0
Sensor card,
Loop
535 12 31-01 Screw
(Torx-20)
1 535 13 03-10 1.0
Chassis, upper
Display cover,
complete
535 13 84-01 Screw
(Torx-20)
4 535 13 03-10 1.0
Pillar, front 544 14 15-01 Screw
(Hex-4)
2 535 07 60-01 3.2
Sensor card
Lift
535 12 31-01 Screw
(Torx-20)
1 535 13 03-10 1.0
Securing ring,
Collision
tower
535 12 16-01 Screw
(Torx-20)
8 535 13 03-10 1.0 Tightened
crosswise
Chassis,
Upper section
535 12 11-01 Screw
(Torx-20)
12 535 13 03-14 1.0 Tightened
crosswise.
IMPORTANT
INFORMATION
Check that
upper and lower
sections are
assembled cor-
rectly, that there
is no dirt in
between and
that no cables
are pinched.
