42 Automower from
3. Installation
™
• If you use a guide wire the charging station must
be placed so that the overall guide loop is not too
long. The guide loop should not be longer than
about 200
metres.
Guide loop = the guide wire from the charging
station to the T-connection on the boundary wire +
the boundary wire from the T-connection (to the
left seen in the direction towards the charging
station) back to the charging station. For more
information about the guide loop, see
1.8.2 Guide
loop on page 13.
3.2 Boundary wire
To start an Automower requires a charging station and
boundary wire to be installed. It is not possible to test
drive a mower until the installation is complete. The
Automower displays the fault message No loop signal
when an attempt is made to start before the installation
is complete.
However, it is possible, to test the mower before the
installation is completed, by connecting a short,
temporary loop in a small area around the mower.
Alternatively you can temporarily deactivate the
mower’s loop detection (see
2.7.5 Loop detection (5-5)
on page 38. Note that this type of special function is
not available to consumers).
3.2.1 Laying the boundary wire
Stapling
It is easier to readjust a stapled boundary wire, as it
does not lie so deep. The function Check loop,
(shortcut 3-4-1) can be used to detect the wire, which
can then be pried up using a screwdriver. Care must
be taken though so as not to damage the wire.
Burying
A buried boundary wire is more protected than a
stapled wire, which may be an advantage if you need
to dethatch or aerated the lawn.
When burying, make a channel using a spade,
approximately 1 – 20 cm deep, around the entire
garden. Place the wire in the channel and then fill it in.
You can also cut a channel using an edge cutting tool.
