Automower from 51
3. Installation
™
3.7 Incline conditions
The incline of a working area can be expressed in
different ways. In table 8 the relation between the
different ways of expressing an incline in per cent,
height-length ratio and in degrees are presented.
3.8 Even mowing result on complex
working areas
Automower is equipped with setting options to assure
an even mowing result on complex working areas too.
The settings are made on the Exit angles (3-1) and
Follow loop out (3-2-1) functions. By not adapting
these settings, the area close to the charging station
would be mown more than areas situated further away
that are accessed via narrow passages. See
3.9
Installation examples on page 52 for examples of the
settings.
Table 8: Incline conditions
Per cent (%) Height – length ratio (1:X) Degrees (°)
10 1:10 6
20 1:5 11
30 1:3.3 17
35 1:2.9 19
40 1:2.5 22
3012-618
Length
Height
x°
