Husqvarna TE 510 User Manual

F.8 Part. N. 8000 B0148 (02-2008)
ENGINE DISASSEMBLY
Valve disassembly
Using a hook, remove the rocker-arm spacer clip.
Remove the fastening screw (5 mm wrench) and the chain slider.
Remove the fastening screws (6 mm wrench) then the rocker-arm axles and the
rocker-arms themselves.

Husqvarna TE 510 Specifications

General

Transmission	6-speed
Front tire	90/90-21
Rear tire	140/80-18
Dry weight	112 kg
Final Drive	Chain
Front suspension (adjustable)	Yes
Rear suspension (adjustable)	Yes
Front brake disc size	260 mm
Rear brake disc size	220 mm
Engine type	Single cylinder, 4-stroke
Fuel system	Keihin FCR-MX 41
Ignition	Electronic
Cooling system	Liquid cooled
Front suspension	Kayaba 48 mm fork
Front brakes	Single disc
Rear brakes	Single disc
