Husqvarna TE 510 User Manual

G.7Part. N. 8000 B0148 (02-2008)
ENGINE OVERHAULING
a: CYLINDER HEAD SIDE
Installation of valves
Lubricate the valve guides and valve stem with oil when the valve is installed.
Install the seal ring, the springs and the cup.
Use tool code 8000 39521 to compress the valve springs and can install halves
cones.
Do not compress the valve springs more than necessary. Do not
damage the cylinder head.

Husqvarna TE 510 Specifications

General

Transmission	6-speed
Front tire	90/90-21
Rear tire	140/80-18
Dry weight	112 kg
Final Drive	Chain
Front suspension (adjustable)	Yes
Rear suspension (adjustable)	Yes
Front brake disc size	260 mm
Rear brake disc size	220 mm
Engine type	Single cylinder, 4-stroke
Fuel system	Keihin FCR-MX 41
Ignition	Electronic
Cooling system	Liquid cooled
Front suspension	Kayaba 48 mm fork
Front brakes	Single disc
Rear brakes	Single disc
