Husqvarna TE 510 User Manual

I.4
Part. N. 8000 B0148 (02-2008)
FRONT SUSPENSION
Front suspension (TE-SMR)
The front suspension unit is a MARZOCCHI “U.S.D.” telescopic hydraulic fork with advanced axle; the diameter of the stem is 50 mm .
The thermal excursion of the wheel on the legs axis is 300 mm (TE) e 250 mm (SMR).
37
31
7
30
29
22
55
28
27
54
53
32
33
34
38
35
36
58
8
9
10
11
12
13
25
21
20
19
34
45
44
49
4
42
33
46
41
39
5
39
6
2
1
2
26
15
16
17
40
40
18
3
48
14
61
8
8
40
TE
SMR

Husqvarna TE 510 Specifications

General

Transmission	6-speed
Front tire	90/90-21
Rear tire	140/80-18
Dry weight	112 kg
Final Drive	Chain
Front suspension (adjustable)	Yes
Rear suspension (adjustable)	Yes
Front brake disc size	260 mm
Rear brake disc size	220 mm
Engine type	Single cylinder, 4-stroke
Fuel system	Keihin FCR-MX 41
Ignition	Electronic
Cooling system	Liquid cooled
Front suspension	Kayaba 48 mm fork
Front brakes	Single disc
Rear brakes	Single disc
