D.26 Part. N. 8000 B0148 (02-2008)
SETTINGS AND ADJUSTMENTS
Adjusting the suspensions according to particular track conditions
The following information is a useful guide for setting up the suspensions according
to the road conditions.
Always start from the standard calibration before making any change on the
suspensions. Afterwards, increase or decrease the adjusting clicks one at a time.
HARD GROUND
Fork: softer compression adjustment.
Shock absorber: softer compression adjustment.
The softer adjustment for the two suspensions is also used both in compression and
in extension when driving at top speed, in order to have better grip of the tires.
SANDY GROUND
Fork: have a harder compression adjustment, or replace the standard spring with
a harder one, and make a softer compression adjustment and a harder extension
adjustment at the same time.
Shock absorber: have a harder compression, and expecially a harder extension
adjustment. Work on the spring preload to lower the motorcycle rear side.
MUDDY GROUND
Fork: have a harder compression adjustment, or replace the standard spring with
a harder one.
Shock absorber: have a harder compression and extension adjustments, or replace
the standard spring with a harder one. Work on the spring preload to lift the
motorcycle rear side.
We advise replacing the springs of both suspensions to compensate the weight
increase due to the piling of the mud.
NOTE:
When the fork results as either too soft or too hard for any adjustment conditions,
check the oil level inside the forkrod.
The level can either be too low or too high. Remember that too much oil inside the
fork will involve a more frequent air drainage. When the suspensions do not react
to the changes of calibration, check that the adjusting units are not blocked.
The standard calibrations, the available springs and the adjustment procedures are
shown on the next pages.
